SPECIFICATION
| Product No | CT1164-A1-RC |
|---|---|
| Ip (A) | 60 |
| Turn Ratio | 1 : 2500 |
| Pri. Opening | 9.0 mm |
| Temp. Operating | -40 ... +85°C |
| Secondary Termination | Pin Terminals |
| Mounting Type | PCB |
| Rb | 37.5 Ω |
| AE % | 0.1 |
| PE (Deg) | 0.2 |
| Secondary Resistance | 62 - 75 Ω |
KEY FEATURES
- High Precision AC whole current transformer
- Low Amplitude Error & Phase error
- High Linearity
- Temperature coefficien
RELATED APPLICATION
- Energy management
- Smart Meter
