SPECIFICATION
| Product No | HS600T01 |
|---|---|
| Nominal Input (Ipn) | 600 Arms |
| Max Input (Ip) | ± 900 A |
| Supply Voltage | ±15 V |
| Output @Ipn | ± 4.0 V |
| Bandwidth -3dB | DC - 50 kHz |
| Accuracy | ±1.0 % |
| Secondary Termination | Connector Header |
| Mounting Type | Panel |
KEY FEATURES
- DC, AC and pulse current measurements with galvanic isolation
- Extended measuring range in the same package.
- Low power consumption
- Good accuracy at nominal currents
RELATED APPLICATION
- Welding machines
- Industrial inverter / UPS
- Battery energy management
